FESTO驅動器574401DRRD-25-180-FH-A

上海天籌 FESTO，F(xiàn)ESTO氣缸,FESTO電磁閥,FESTO過濾器,FESTO減壓閥，F(xiàn)ESTO磁性開關，F(xiàn)ESTO壓力計，F(xiàn)ESTO傳感器FESTO防爆閥,FESTO緩沖器，F(xiàn)ESTO流體閥，F(xiàn)ESTO馬達.FESTO手動閥，F(xiàn)ESTO線性滑臺，F(xiàn)ESTO組合機械手，F(xiàn)ESTO卡爪，F(xiàn)ESTO浮動接頭，F(xiàn)ESTO氣動元件,上海FESTO代理——上海天籌

FESTO驅動器574401DRRD-25-180-FH-A部分型號：

574399 DRRD-16-
1577238 DRRD-16-180-FH-PA
1644389 DRRD-16-180-FH-Y9A
574400 DRRD-20-
1395606 DRRD-20-180-FH-PA
1427379 DRRD-20-180-FH-Y9A
574401 DRRD-25-
1359980 DRRD-25-180-FH-PA
1360248 DRRD-25-180-FH-Y9A
574402 DRRD-32-
1578512 DRRD-32-180-FH-PA
1578518 DRRD-32-180-FH-Y9A
574403 DRRD-35-
1526825 DRRD-35-180-FH-PA
1547102 DRRD-35-180-FH-Y9A
574404 DRRD-40-
1503269 DRRD-40-180-FH-PA
1526986 DRRD-40-180-FH-Y9A
574405 DRRD-50-
574407 DRRD-63-


FESTO驅動器574401DRRD-25-180-FH-A

上海天籌 FESTO，F(xiàn)ESTO氣缸,FESTO電磁閥,FESTO過濾器,FESTO減壓閥，F(xiàn)ESTO磁性開關，F(xiàn)ESTO壓力計，F(xiàn)ESTO傳感器FESTO防爆閥,FESTO緩沖器，F(xiàn)ESTO流體閥，F(xiàn)ESTO馬達.FESTO手動閥，F(xiàn)ESTO線性滑臺，F(xiàn)ESTO組合機械手，F(xiàn)ESTO卡爪，F(xiàn)ESTO浮動接頭，F(xiàn)ESTO氣動元件,上海FESTO代理——上海天籌


FESTO驅動器574401DRRD-25-180-FH-A系列參數：

特性                                           特性
尺寸                                            25
擺動角度                                       180 deg
緩沖                                  P: 兩端帶彈性緩沖環/板
                                      Y9: 內部液壓緩沖，正常
                                      Y10: 內部液壓緩沖，硬
                                      Y12: 外部液壓緩沖
裝配位置                                       任意
設計結構                                    齒輪齒條機構
多可實現的中間位置數量                           1
位置檢測                                   用于接近式傳感器
工作壓力                                     2 ... 10 bar
工作模式                                        雙作用
ATEX 類氣體                                      II 2G
燃爆防護型氣體                                    c T4
ATEX 類粉塵                                      II 2D
燃爆防護型粉塵                                 c T120°C
符合防爆要求的環境溫度                  -10°C <= Ta <= +60°C
工作介質                         壓縮空氣符合ISO8573-1:2010 [7:4:4]
關于工作和先導介質的說明  可以使用經過潤滑的壓縮空氣 (一旦使用后要求一直使用經過潤滑的壓縮空氣)
                          CE 符號 (參見符合的標準)  根據 EU-Ex 防爆指導原則 (ATEX)
環境溫度                                       -10 ... 60 °C
6 bar時的理論扭矩                                  5.15 Nm
允許的質量慣性矩                             0.09 ... 0.55 kgm2
安裝類型                                              可選
                                                      帶通孔
                                                  具有內（陰）螺紋
氣動連接                                                 M5
材料備注                                           含有PWIS 物質
符合                                                     RoHS
驅動軸的材料信息                                       熱處理鋼
蓋子的材料信息                                         鍛造鋁合金
                                                        陽極氧化處理
密封件的材料信息                                            NBR
                                                         TPE-U(PU)
外殼的材料信息                                         鍛造鋁合金
                                                       光滑處理
